Nachtsichtgerät monokular Generation 2+

Dieser Nachsichtgerät ist mit  Bildverstärker Gen. 2+ DEP SuperGen ausgestattet. Gen. 2+ DEP SuperGen von Photonis hat Auflösung min. 45/51 lp/mm als Type 1/Type 2, S/N ratio min. 18, Fotokatodesensitivität ist min. 500 µA/lum und Restlichtverstärkung ist zwischen min. 20 000x und max. 70 000x. Lebensdauer sind minimal  7 500+ Arbeitstunden ohne Bildveränderung. Rohre ist sehr widerstandsfähig gegen Rückstosse bis +/- 500 g (gesamt 1000 g) im beiden Achsen während 2 ms +/- 0,2 ms.

Description:

The Armasight Nyx-14 is the new standard by which all compact multi-use monoculars will be judged in future.  The Nyx-14 uses optics that are equal to or better than current Military issue night vision units, built into a tough, compact and ergonomic composite housing. We built this body to surpass MIL-SPEC-810 specifications, and so the Armasight Nyx-14 can withstand salt water, rain, high humidity, extremes of temperature and still give unsurpassed levels of performance.
The Nyx-14 mini-monocular is equipped with manual variable gain control so that the image brightness level can be selected by the user to adjust for the ambient light level in his area of operations. The Armasight Nyx-14 is available with a whole array of accessories like – 3, 5 and 8X magnification lenses for mid-long range viewing, head or helmet mounts to allow the unit to be worn as a mono-goggle, various different weapon mounts for tactical or hunting use and high powered additional IR illuminators for long range use.  The Nyx-14 is available in Gen 2+ and Gen 3 variants, and is the only night vision device that will meet the challenge of such a high number of tasks and accomplish them all with ease.


Features:

•    Compact, rugged design
•    Waterproof
•    Weapon mountable
•    Head or helmet mountable for hands-free usage
•    Manual brightness control
•    Bright light cut-off
•    Ergonomic, simple, easy to operate controls
•    Utilizes single CR123A lithium or AA battery
•    Adaptable for use with cameras
•    Built-in Infrared illuminator and flood lens
•    Limited two-year warranty


Specifications:

Magnification    1x standard, 3x, 5x, 8x optional
Multi-Purpose System    Yes
Photocathode Type    Multi-Alkali
Lens System    F1.2, 27 mm
FOV    40°
Range of Focus    0.25 m to infinity
Diopter Adjustment    -6 to +2 dpt
Controls    Direct
Automatic Brightness Control    No
Bright Light Cut-off    Yes
Automatic Shut-off System    Yes
Infrared Illuminator    Yes (built-in flood lens)
IR Indicator    Yes (in FOV)
Low Battery Indicator    Yes (in FOV)
Power Supply    1x CR-123 Lithium 3V or 1x AA Alkaline
Battery Life    60 hrs
Environmental Rating    Waterproof / MIL-STD-810 Complies
Operating Temperature    -40 to +50 °C
Storage Temperature    -50 to +60 °C
Dimensions    140 x 49 x 69 mm / 5.5 x 1.9 x 2.7 in
Weight    0.4 kg / 0.88 lbs
Warranty    2 Year
